HL S120N04D
Manufacturer:
HL
Asian Brands
Mfr. Part #:
S120N04D
Package:
PDFN3x3-8L
Customer #:
Key Attributes:
MOSFET 40V 120A PDFN3x3-8L
Description:
40V 120A 65.7W Surface Mount PDFN3X3-8L
Datasheet:
HL S120N04D
Products Specifications
Manufacturer:
Package:
PDFN3x3-8L
Drain to Source Voltage:
40V
Current - Continuous Drain(Id):
120A
RDS(on):
2.8mΩ@10V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
2.2V@250uA
Reverse Transfer Capacitance (Crss@Vds):
25pF
Number:
1 N-channel
Output Capacitance(Coss):
560pF
Pd - Power Dissipation:
65.7W
Input Capacitance(Ciss):
2.625nF
Gate Charge(Qg):
42.6nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 5000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
HL
282 Products
HL is located in Shenzhen, China, and is a national high-tech enterprise focusing on MCUs, motor drivers, and system control. The company primarily produces microcontroller units (MCUs), motor driver chips, and related products for system control.
