hengjiaxing HX6291
Manufacturer:
hengjiaxing
Asian Brands
Mfr. Part #:
HX6291
Package:
SOT-23-6
Customer #:
Key Attributes:
1MHz, 2.5A Step-Up Current Mode PWM Converter
Description:
Boost 800kHz~1.2MHz Adjustable 600mV~12V 2.5A SOT-23-6 Voltage Regulators - DC DC Switching Regulators RoHS
Datasheet:
hengjiaxing HX6291
Products Specifications
Category:
Manufacturer:
Package:
SOT-23-6
Operating Temperature:
-40℃~+85℃@(TA)
Function:
Boost
Frequency - Switching:
800kHz~1.2MHz
Number of Outputs:
1
Output Type:
Adjustable
Topology:
Boost
Operating Voltage:
2.6V~5.5V
Switch tube (built-in/external):
Built-in
Output Voltage:
600mV~12V
Output Current:
2.5A
Quiescent Current:
190uA
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8542399000 |
| USHTS | 8542390001 |
| TARIC | 8542399000 |
| CAHTS | 8542390000 |
| BRHTS | 85423999 |
| INHTS | 85423900 |
| MXHTS | 8542.39.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
hengjiaxing
179 Products
Shenzhen HengJiaXing Electronics Co., Ltd.
(hereinafter referred to as "HengJiaXing" or "HX") was established in 2004. It is a comprehensive enterprise integrating solution development, agency support and technical support, focusing on power IC, MOS, single-chip microcomputer and solution development. Products are widely used in intelligent robots, small household appliances, 3C consumer electronics, security monitoring, car navigation, smart home and other fields. HengJiaXing has always been adhering to the warehousing-style business philosophy, with professionalism, integrity and service as its purpose, to provide customers with diversified and comprehensive quality services.
