hanxia HX PZ2.54-3x5P ZZ
Manufacturer:
hanxia
Mfr. Part #:
HX PZ2.54-3x5P ZZ
Package:
Through Hole,P=2.54mm
Customer #:
Description:
Pin Header 15 Position 2.54mm Pitch Triple Row Through Hole -40℃~+105℃
Datasheet:
hanxia HX PZ2.54-3x5P ZZ
Products Specifications
Manufacturer:
Package:
Through Hole,P=2.54mm
Number of Pins:
15P
Pins Structure:
3x5P
Contact Plating:
Gold
Contact Material:
Brass
Operating Temperature:
-40℃~+105℃
Color:
Black
Circluar Pins/Square Pins:
Pin Header
Supplementary Features:
-
Pitch:
2.54mm
Insulation Height:
2.5mm
Length of Mating Pin:
6mm
Voltage Rating (Max):
1kV
Length of End Connection Pin:
3mm
Number of Rows:
3
Current Rating-Signal:
3A
Mounting Type:
Through Hole
Row Spacing:
2.54mm
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8536901100 |
| USHTS | 8536908585 |
| TARIC | 8536901000 |
| CAHTS | 8536900090 |
| BRHTS | 85369010 |
| INHTS | 85369010 |
| MXHTS | 8536.90.11 |
