HANSCHIP semiconductor TLC2543IDRG
Manufacturer:
HANSCHIP semiconductor
Asian Brands
Mfr. Part #:
TLC2543IDRG
Package:
SOP-20-300mil
Customer #:
Key Attributes:
12-BIT ANALOG-TO-DIGITAL CONVERTER WITH SERIAL CONTROL AND 11 ANALOG INPUTS
Description:
-40℃~+85℃ SPI 4.5V~5.5V SOP-20-300mil Analog to Digital Converters (ADC) RoHS
Datasheet:
HANSCHIP semiconductor TLC2543IDRG
Products Specifications
Manufacturer:
Package:
SOP-20-300mil
Temperature Range:
-40℃~+85℃
Clock/Oscillator:
Built-in
Clock Frequency:
4.1MHz
Voltage Reference:
External
Interface:
SPI
Quiescent Current (Iq):
2.5mA
Resolution(Bits):
12
Voltage - Supply:
4.5V~5.5V
Number of Channels:
11
ADC architecture:
SAR
Integral non - linearity:
1LSB
Programmable Gain:
Not supported
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 2000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8542399000 |
| USHTS | 8542390001 |
| TARIC | 8542399000 |
| CAHTS | 8542390000 |
| BRHTS | 85423999 |
| INHTS | 85423900 |
| MXHTS | 8542.39.99 |
