FG XHD-2*3AW
Manufacturer:
FG
Asian Brands
Mfr. Part #:
XHD-2*3AW
Package:
Through Hole,Right Angle,P=2.5mm
Customer #:
Key Attributes:
CONN HEADER TH R/A 6POS 2.5mm
Description:
Connector Header 6 position 2.5mm Pitch 3A Right Angle -25℃~+85℃
Datasheet:
FG XHD-2*3AW
Products Specifications
Manufacturer:
Package:
Through Hole,Right Angle,P=2.5mm
Y-Width of Bottom Edge on Board:
12.5mm
Reference Series:
-
Pins Structure:
2x3P
Contact Plating:
Tin
Contact Material:
Brass
Pitch:
2.5mm
Voltage Rating (Max):
250V
Number of PINs Per Row:
3
Number of Rows:
2
X-Length of Bottom Edge on Board (Spacing Line):
10mm
Z-Height of the Board:
8.6mm
Operating Temperature:
-25℃~+85℃
Mounting Type:
Right Angle
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 1000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8536901100 |
| USHTS | 8536908585 |
| TARIC | 8536901000 |
| CAHTS | 8536900090 |
| BRHTS | 85369010 |
| INHTS | 85369010 |
| MXHTS | 8536.90.11 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
FG
1164 Products
FUGANG electronics co.,ltd. Was found in 2005 year,it specializes in produce,Design and sale of HDMI Socket,Tact switch,Power Jack,AV Jack,Din terminal,USB,Wafer and Modular Jack etc. Our product are Used in HDTV,Computer,DVD decoders board,MP3/MP4，Audio，Multimedia communication,Ait condition Etc. And these products are sold to well-known enterprises at home and abroad. We set up the AV Automated ssembly production line,USB automated assembly production line, hole-socket automated Assembly production line , modular jack automated assembly production line.
