ElecSuper IRF5305PBF(ES)
Manufacturer:
ElecSuper
Asian Brands
Mfr. Part #:
IRF5305PBF(ES)
Package:
TO-220F
Customer #:
Key Attributes:
MOSFET P-CH 60V 24A TO-220F
Description:
60V 24A 1.6V 43W TO-220F Single FETs, MOSFETs RoHS
Datasheet:
ElecSuper IRF5305PBF(ES)
Products Specifications
Manufacturer:
Package:
TO-220F
Drain to Source Voltage:
60V
Current - Continuous Drain(Id):
24A
RDS(on):
27mΩ@10V;31mΩ@4.5V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
1.6V
Type:
P-Channel
Reverse Transfer Capacitance (Crss@Vds):
159pF
Pd - Power Dissipation:
43W
Input Capacitance(Ciss):
3.941nF
Output Capacitance(Coss):
191pF
Gate Charge(Qg):
46.6nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 50 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
