Econd 22uF400V13x18KM
Manufacturer:
Econd
Asian Brands
Mfr. Part #:
22uF400V13x18KM
Package:
Through Hole,D13xL18mm
Customer #:
Description:
22uF 400V 3Ω ±20% 165mA@120Hz Through Hole,D13xL18mm Aluminum Electrolytic Capacitors RoHS
Datasheet:
Econd 22uF400V13x18KM
Products Specifications
Manufacturer:
Package:
Through Hole,D13xL18mm
Lifetime:
2000hrs@105℃
Operating Temperature:
-25℃~+105℃
Capacitance:
22uF
Height - Seated (Max):
18mm
Pin Spacing:
5mm
Voltage Rating:
400V
Diameter:
13mm
Equivalent Series Resistance(ESR):
3Ω
Tolerance:
±20%
Ripple Current:
165mA@120Hz
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 200 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8532229000 |
| USHTS | 8532230020 |
| TARIC | 8532220000 |
| CAHTS | 8532220000 |
| BRHTS | 85322200 |
| INHTS | 85322200 |
| MXHTS | 8532.22.99 |
