DIODES AP1534SG-13
Manufacturer:
DIODES
Mfr. Part #:
AP1534SG-13
Package:
SOP-8
Customer #:
Key Attributes:
AP1534 Step-Down Converter
Description:
300kHz Buck Adjustable 800mV~18V 2A SOP-8 Voltage Regulators - DC DC Switching Regulators RoHS
Datasheet:
DIODES AP1534SG-13
Products Specifications
Category:
Manufacturer:
Package:
SOP-8
Operating Temperature:
-40℃~+125℃
Frequency - Switching:
300kHz
Function:
Buck
Number of Outputs:
1
Output Type:
Adjustable
Topology:
Buck
Operating Voltage:
3.6V~18V
Switch tube (built-in/external):
Built-in
Output Voltage:
800mV~18V
Output Current:
2A
Quiescent Current:
-
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8542399000 |
| USHTS | 8542390001 |
| TARIC | 8542399000 |
| CAHTS | 8542390000 |
| BRHTS | 85423999 |
| INHTS | 85423900 |
| MXHTS | 8542.39.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
DIODES
6026 Products
Diodes Incorporated is a leading global manufacturer and supplier of high-quality application specific standard products within the broad discrete, logic, analog and mixed-signal semiconductor markets.
