Broadcom ACPL-224-560E
Manufacturer:
Broadcom
Mfr. Part #:
ACPL-224-560E
Package:
SO-8
Customer #:
Key Attributes:
AC Input, Multi-Channel Half-Pitch Phototransistor Optocoupler
Description:
50mA 400mV@8mA,2.4mA 80V 6V AC,DC SO-8 Transistor, Photovoltaic Output Optoisolators RoHS
Datasheet:
Broadcom ACPL-224-560E
Products Specifications
Manufacturer:
Package:
SO-8
Fall time:
3us
Rise time:
2us
Output Current:
50mA
Vce Saturation(VCE(sat)):
400mV@8mA,2.4mA
Operating Temperature:
-55℃~+110℃
Load Voltage:
80V
Reverse Voltage:
6V
Current transfer ratio:
400%;20%
Forward Current(If):
-
Number of Channels:
2
Pd - Power Dissipation:
200mW
Load Type:
Phototransistor
Input type:
AC,DC
Isolation Voltage(Vrms):
3.75kV
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541490000 |
| USHTS | 8541491010 |
| TARIC | 8541490000 |
| CAHTS | 8541490090 |
| BRHTS | 85414900 |
| INHTS | 85414900 |
| MXHTS | 8541.40.02 |
