AIPULNION FD20-36S24A3C
Manufacturer:
AIPULNION
Asian Brands
Mfr. Part #:
FD20-36S24A3C
Package:
DIP,25.4x25.4mm
Customer #:
Key Attributes:
DC/DC modular power supply, wide-range input, output power 20W
Description:
Isolated Module DC DC Converter 1 Output 24V 833mA 18V~75V Input
Datasheet:
AIPULNION FD20-36S24A3C
Products Specifications
Manufacturer:
Package:
DIP,25.4x25.4mm
Height:
21.3mm
Vin:
18V~75V
Vout:
24V
Operating Temperature:
-40℃~+85℃
Capacitive Load(Max):
500uF
Number of Outputs:
1
Ripple:
50mVp-p
Length:
76mm
Iout:
833mA
Width:
31.5mm
Frequency - Switching:
350kHz
Isolation Voltage(Vrms):
1.5kV
Conversion Efficiency:
90%
Output Power:
20W
Features:
Under Voltage Protection
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 10 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | - |
| USHTS | - |
| TARIC | - |
| CAHTS | - |
| BRHTS | - |
| INHTS | - |
| MXHTS | - |
